Product Details:
|
| Name: | Automatic Book-Type Box Assembly Machine | Application: | Food Boxes |
|---|---|---|---|
| Type: | Boxing Machine | Color: | Customized Color |
| Weight: | 1200kg | Speed: | 20-28units/min |
| Positioning Accuracy: | ±0.2mm | Power: | 3.2kw |
| Highlight: | fully automatic rigid box making machine,automatic rigid box machine,automatic gift box making machine |
||
Automatic Rigid Box Assembly Machine
Product description
Book box assembly machine is easy to use, high efficiency, save glue, accurate positioning, is the book box manufacturers to reduce the production cost of the preferred equipment. The machine adopts automatic positioning robot to spray glue, which can be adjusted according to the size of the product. Strip spraying is adopted to reduce the waste of glue, and at the same time to ensure the accuracy, bonding strength and no leakage. The machine adopts positioning pressure box, which improves the accuracy of inner box and leather shell in the positioning process, reduces the reject rate, and new products are launched, which are well received by customers.
Product features
1. Adopt strip spraying, save glue, strong adhesion, no leakage;
2. Robot hand positioning, high precision;
3. Positioning pressure box, precise adhesion between leather shell and inner box, no bubbles, no scratches;
4. Easy to use and high efficiency.
Teachnical Parameter
| TECHNICAL SPECIFICATIONS | |
| ITEM NO | WM-9045A |
| SIZE | 3300x1560x1700 |
| machine weight | 1200KG |
| SPRAYER Qty | 1 |
| Feed system | Automatic pneumatic continuous large capacity for glue |
| Production Speed | 20-28units/min |
| Max.Size(Hardbook Case) | (L)900mm*(W)450mm |
| Min.Size(Hardbook Case) | (L)110mm*(W)90mm |
| Max Size(Inner Box Size) | (L)400mm*(W)450mm*(H)150mm |
| Min Size(Inner Box Size) | (L)90mm*(W)45mm*(H)15mm |
| Positioning Accuracy | ±0.2mm |
| Voltage | 220V/50HZ |
| Power | 3.2KW |
| Air Pressure | >0.6MPa |
Product application
The book box assembly machine is mainly used for gluing mooncake boxes, food boxes, wine boxes and other book boxes.
Packing and Shipping
Packaging Details: wooden case
